Ruijie RG-S6120-20XS4VS2QXS

20 1G/10GBASE-X SFP+ ports, 4 10G/25GBASE-X SFP28 Ports, 2 40GBASE-X QSFP+ ports, support up to 32 10G ports, 2 modular power supply slots (at least one RG-PA150I-F power module needed, no power module in default), 2 modular fan slots (2 fan modules are equipped by default)

Specification

  • Service port

20 x 1G/2.5G/10G SFP+ ports, 4 x 10G/25G SFP28 ports, 2 x 40G QSFP+ ports
One switch provides a maximum of 32 x 10G ports, 2 modular power slots, and 2 modular fan slots.



  • Switching capacity

2.56 Tbps/25.6 Tbps



  • Number of MAC addresses

Number of global MAC addresses: 32,768
Number of static MAC addresses: 1,000



  • Operating temperature

0 - 50°C



  • Management

1 x MGMT port, 1 x console port, and 1 x USB 2.0 port



  • Forwarding rate

570 Mpps/1,260 Mpps



  • Dimensions (W x D x H)

442 mm × 330 mm × 43.6 mm (17.40 in. x 12.99 in. x 1.72 in.), 1 RU



  • Warranty duration

3 years
