RG-CS85-24SFP/8GT8XS-D

48 10G Ethernet fiber ports (SFP+, LC) service module

Specification

  • Service port

48 x 10/100/1000 Mbps electrical ports with auto-negotiation,4 × 1G/10G SFP+ ports, and two modular power slots, PoE/PoE+ supported



  • Switching Capacity

176Gbps/656Gbps(including expansion module)



  • Cooling mode

Fan cooling



  • DC

240 VDC



  • Link Aggregation

Supported



  • Operating Temperature

0 - 45°C



  • PoE

Supported



  • Management port

1 x management port, 1 x console port, and 1 x USB 2.0 port



  • Forwarding rate

131Mpps/488Mpps(including expansion module)



  • AC

100 - 240 VAC,50/60 Hz



  • Power Consumption

< 120 W (without expansion module), or < 1600 W (fully loaded)



  • Dimensions (W x D x H)

440 mm x 340 mm x 43.6 mm



  • Warranty period

3 years
